Panel-Tec
Innovative silos in modular construction
Custom-made silos with innovative flange design
Zeppelin Systems, as a global leader in plant engineering, also demonstrates exceptional expertise in the cost-effective construction of silos over 500 m³. The Panel-Tec design, featuring innovative flange design and well-thought-out assembly technologies, impresses with short assembly times while maintaining verifiable Zeppelin quality. The concept: individual silo segments are prefabricated as much as possible at our production facility and fitted with flanges. These segments are transported to the construction site in containers, where they are assembled and bolted together. The silos are then automatically welded from the inside. This ensures that the silos are ready for use in the shortest time, regardless of weather conditions. Additionally, they are expandable – if more storage capacity is needed in the future, the silo can be easily and quickly expanded.
Benefits
Special Highlights
Simple and Efficient Assembly
The silo systems are designed for quick and easy assembly, minimizing time and labor effort.
Optimal Bulk Material Flow
Thanks to the thoughtful design, a continuous and consistent flow of bulk materials is ensured, enhancing the efficiency of the entire system.
Lower Transport Costs
The compact design and modular silo segments ensure optimal utilization of transport vehicles, thereby reducing transportation costs.
Transport & Team
The experienced Zeppelin construction team ensures fast and smooth installation on-site, while the silo segments are optimized for cost-effective transport by truck or sea container.
Holistic Excellence: Design, Quality, Safety, Performance, and Service
Convincing Design
- Flexible diameters available: 5000 – 10000 mm
- Storage capacities/volume: 500 – 2000 m³
- Various cone opening angles: 60°, 50°, 40°
- Design pressures: -20 mbar to +200 mbar
- The shell segments with a height of 2000 mm can be packed and transported in standard containers. On-site, they are bolted together longitudinally to ensure precise positioning.
- Low crane costs due to the fast stacking of bolted flanges
- Standardized silo design ensures efficient use of materials and labor hours.
Unique Quality
- Verifiable welding quality ensures cost advantages
- X-ray secure longitudinal seams through weld pool protection
- Experienced teams with welders trained by Zeppelin
- Zeppelin's own welding machines
100% Safety
- Individual static design, prefabrication, and assembly based on the Eurocode DIN EN 1090-3 standards
- TÜV-certified welders for deployment
Outstanding Performance
In our laboratories and test center, we offer a range of product tests. This ensures a customized design and discharge solution, even for challenging bulk materials.
