SFG vacuum hopper loader


The SFG vacuum hopper loader can be used for the automatic feeding of extruders, processing machines, containers and storage silos with powders and pellets.

Direct Inquiry

Your request

Reason for contacting us*


e.g. +49


500 characters remaining

* Required field

SFG vacuum hopper loader


  • High-performance bag filter with compressed-air cleaning
  • Filter is easily replaced when changing to a different product, as filter plate and hoses are a single unit
  • Parts coming into contact with product are made from stainless steel
  • Electro-pneumatically operated sealing cone at outlet
  • Filling-level control at base skirt
  • Easy access to filter elements
  • Fully pre-piped and pre-wired for control system
  • Electrical control system
  • Large filter surface
  • Large outlet cross-section
  • Temperature range from -10 to +80°C
  • Operating pressure between -0,5 bar and +0.05 bar (g)

Equipment configurations, options and accessories:

  • Continuous conveying possible through the use of a discharge feeder instead of the sealing cone
  • Special filter materials and cartridges
  • Aeration nozzles in outlet for arch-forming materials
  • Maximum-level indicator in container
  • Master control unit: To use up to 5 devices with a single vacuum pump
  • Suitable for ATEX 2014/34/EU Zone 2/22; 1/21; 20 (interior)
